- L1= 85,5mm
- L2= 78,5mm
- R1= 3/4" BSP
- HEX2=36mm
- ØE=47,5mm
- Átfolyás: DN25
- Névleges áramlás: 106l/min
- Maximális áramlás: 190l/min
- Opcionális tömítések: FKM, EPDM....
- Üzemi nyomás max.: 300 bar
- Csatlakozás maradék nyomás alatt: nem megengedett
